|automatic grade:||fully automatic||raw material:||mgo ,mgcl2, fiber grass mesh|
Construction Material Making Machinery,
polyurethane sandwich panel machine
Fireproof Mgo Board Production Line For Magnesium Oxide Board Manufacturing Process
About this production line ,among which ,Glue spreading-overlaying-daying Machine and Glazing Machine are equipment which will give the advanced processing to the boarad .the above two machine s can overlay and glaze the magnesium oxide board or orinary wood board . The Glue spreading-overlaying-daying Machine can overlay wood-grain paper,PVC film .The Glazing Machine will glaze the overlaied board with wood-grain paper,and make the board with bright light or dull light .The above processing will replace former painting working processing .(because the wood-grain paper is not wearable and it has no gloss degree)
EQUIPMENT CONTRIBUTION CONDITIONS:
2. Technoloy features:
There is not any requirement about high temperature and high pressure during production processing .the boarad will be formed at one time after roller-extruding under the conditions of normal temperation and normal pressure .this is a green environmental-protection project, because that there is no waste water ,waste materials and waste gas during its production processing .the finised board don’t need high temperature drying ,air-drying and watering ,and under the normal temperature ,they will dry well indoor .
MGO BOARD CONSUMPTION COMPARABLE TABLE:
|Names of materials||Each dosage|
|Magnesium chloride||1.23 yuan|
|Glass cloth||1.05 yuan|
3. Production process:
All the required componments of the main board processing line are supplied by Chinese manufactures.In addition they provide all the ancillary equipment such as mixers .
Raw Material Delivery
Raw materials arrive at the plant via truck and rail transport in a variety of forms and packaging .mgo power is delivered via pneumatic trailer and piped into outside 150-ton mobile silos called a pig or guppy trailer .mgcl2 is delivered in liquid tanker truck and piped into outside 32,000-gallon vertical tank farm wood chips,the largest commodity is delivered in modular containers and stockpiled outside the plant.the comparably smaller balance of raw materials ,are deliver in bulk or standard bag format and stored inside the plant on pallets ,all the materials are sampled as they arrive and sent to the lab to maintain quality control.
Mixing and batching platform
A steel superstructure of several 1000 sq. Ft.sits above the beginning of the board processing line .this elevated platform or second level is where all the recipe ingredients for the board is collected ,batched and mixed. Ingredients arrived at the platform via fluid piping ,pneumatic or screw conveyor into batch containers such as 5-ton silos and tanks,any baggede material for the recipe is opened on the ground floor in a bag-breaking machine and conveyed up the intermadiate storage on the platform
Board processing line
The board machine system is overall 160 ft long with all components .
After receiving the board mixture on the PVC sheets the mixture is squeezed through pinch rollers that determine the board thickness,these rollers can be adjusted to a variety of spacing providing the boards final thickness.
Spindles above the board processing line hold spools of meshed fiberglass or basalt fiber material that are rolled out into the board mixture ,this adds strength to the board and multiple layers of mesh material can even make the board bullet proof.
The boards progress down the line and are cut into specified lengths matching the underlying PVC panel. The cut board lengths are then ejected into a drying tray rack that typical holds 18PVC trays and performed boards
The finished board are then palletized in a palletizing machine and stretch hood wrapped in bundles of mgo board per pallet .for overall product management and quality control board packages are labeled(lot number) per the quality control standards and moved to either indoor warehousing or outside storage area.
