EPS Sandwich Wall Board Forming Machine for Building Construction Material

EPS Sandwich Wall Board Forming Machine for Building Construction Material
EPS Sandwich Wall Board Forming Machine for Building Construction Material EPS Sandwich Wall Board Forming Machine for Building Construction Material EPS Sandwich Wall Board Forming Machine for Building Construction Material EPS Sandwich Wall Board Forming Machine for Building Construction Material

صورة كبيرة :  EPS Sandwich Wall Board Forming Machine for Building Construction Material

تفاصيل المنتج:
Place of Origin: CHINA
اسم العلامة التجارية: chuangxin
إصدار الشهادات: ce
Model Number: XD-D
شروط الدفع والشحن:
Minimum Order Quantity: 1 sets
الأسعار: negotation
Packaging Details: packing
Delivery Time: 30 days
Supply Ability: 10 sets per month

EPS Sandwich Wall Board Forming Machine for Building Construction Material

وصف
Production capacity: 2000sqm Warranty: 1 years
Automatic grade: Automatic
تسليط الضوء:

wall making machine

,

roof panel roll forming machine

EPS Sandwich Wall Board Forming Machine for Building Construction Material



 EPS Sandwich Wall Board Forming Machine And Fiber Cement Board Production Line







Item National Standards Testing Indexes
90mm 90mm
1 Anti-impact Capacity ≥5 ≥10
2 Anti-bending damage load ≥1.5 ≥4
3 Compressive strength/Mpa ≥3.5 ≥5
4 Softening coefficient ≥0.80 ≥1
5 Facial surface density g/cubic meters ≤90 ≤70
6 Water absorption ≤10 ≤9
7 Drying shrinkage% ≤0.6 ≤0.5
8 Hanging force/N ≥1000 ≥1500
9 Sound insulation/dB ≥35 ≥50
10 Fireproof limit/h ≥1 ≥3
11 Heat transfer coefficient w/m2 ≤1.0 ≤1.0
12 Radioactivity limit ≤1.0 ≤1.0
13 IRa(interior radiation indexes) ≤1.0 ≤1.0
14 lr(exterior radiation indexes) ≤1.0 ≤1.0

1

Air-dry density

≤ (Standard index)

50kg/m2

(Test Value)

 30.0kg/ m2

2

Drying shrinkage

rate of the board

≤0.08%

0.015%

3

Anti-breaking load

≥1400N

5640N

4

Anti-impact

No breakage phenomenon

such as cracking

 after three impacts

No breakage phenomenon

 such as cracking after

 three impacts

5

Thermal resistance

 of main section

(T=90mm)

≥1.35(m2.k)/w

≥1.36(m2.k)/w

6

Thermal bridges area ratio

≤8%

2.22%

7

Sound insulation Index



36dB

8

Radioactivity



None







III  Feature

 1. Anti-earthquake with light weight: In view of its weight per unit area is only 1/10 of red brick wall, the product has good anti-earthquake performance. It can be used at low-rise building and high-rise building, and it is preferred to be used at workshop with steel frame structure. It can replace the color steel plate with its better performance.

2. Fast and convenient operation: It can be installed by board or combination with the dry method, and the product can be nailed, cut, planed, drilled and stuck.

3. Low comprehensive cost: The product is made of agricultural and industrial wastes, so the production cost is low. With the low load of girder and short construction period, it can reduce over 20% of engineering cost after compared with solid brick and hollow brick.

 4. Energy-saving and environmental protection: The production processing need no high temperature and high pressure. Being a green environmental-protection energy-saving building materials, the product has no toxicity, harm, pollution and radioactivity.

5. Increasing the usage area: Under the same condition of heat-preserving and sound insulation, with the thinner plate, the product can increase over 10% usage area after compared with the same building.

 6. Having the following features: fireproofing, water-proof, anti-impact, acid & alkali resistant and anti-aging.
