Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness

Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness

    • Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness
    • Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness
    • Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness
    • Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness
  • Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness

    تفاصيل المنتج:

    Place of Origin: China
    اسم العلامة التجارية: chuangxin
    إصدار الشهادات: CE
    Model Number: XD-A

    شروط الدفع والشحن:

    Minimum Order Quantity: 1 set
    الأسعار: negotiation
    Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
    Delivery Time: 30 working days after received your payment
    Payment Terms: L/C, T/T
    Supply Ability: 50 Sets per year
    ﺎﺘﺼﻟ ﺍﻶﻧ
    مفصلة وصف المنتج
    Product Name: roof tile machine raw material: Mgo,mgcl,fiber glass mesh
    type: free standing

    Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness



    Product description



    Mgo roof tile forming machine can produce glazed, or PET film coated MGO roofing tiles with all kinds of waves and heat-preserving layer, which will be used at the roof as the substitute of traditional asbestos tile, color steel tile and cement tile.

    2. Machine Model:

    According to different production capacity from 300 tiles to 900 tiles per eight

    hours the tile-making machine has different models for large-scale, middle-scale and small-scale.

    Equipment Model and Product Specification

    According to different production, our equipment has 6 models for large-scale, middle-scale and small-scale. Our all equipment can produce board with same quality and specification but different production.

    Customers can adjust the specification of the pantile according to different requirements, the standard specification is 1.8mX0.72m, the biggest length is 6 m, the thickness is 3mm~6mm generally. In addition, this equipment can produce the pantile with heat-preserving layer.

    All machine can produce tile with same best-quality and specification board, only

    has different production capacity.



    3. Application of Roof Tile

    The roof tile produced by our machine with all kinds of waves and heat-preserving

     layer, which will be used at the roof as the substitute of traditional asbestos tile,

    color steel tile and cement tile. There is asbestos in the asbestos tile which include

     carcinogen.



    4. Tile performance:

    Performance

    Standard

    Test Value

    Transverse breaking-resistance

    7/3000N/M

    4900 N/M

    Vertical breaking-resistance

    7/200 N/M

    320N/M

    Anti-impact force

    No chap, peeling and crack

    None

    Water absorption

    26%

    14%

    Imperviousness

    No spot and water

    drop on the back of pantile

    after it was watering

    None

    Frost resistance

    No phenomenon of layer-producing after 25

     times freezing-thawing

    No phenomenon of

     layer-producing

    Artifical chalking grade

    None

    None

    Climate Aging Change Grade

    ≤2

    None

    Climate Aging Chromatism Grade

    E≤3

    0.66



      Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm ThicknessGlazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness

    Mgo roof tile Machine
