Product Details:
Place of Origin: China
Brand Name: chuangxin
Certification: CE
Model Number: XD-DB
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 50 Sets per year

Sandwich Wall Panel Fiber Cement Board Production Line , Mgo Board Production Line

Description
Product Name: Building Moulding Board Machine Production Capacity: 1500 Sheets
Warranty: 1 Years Standard: CE
Type: Free Standing
High Light:

fiber cement board machine

,

sheet forming machine


 Sandwich Wall Panel Fiber Cement Board Production Line , Mgo Board Production Line



Multi-functional Board Production Line

It not only can produce Wall Panel, but also produce Single MgO board.



1. Specification of Board:



Wall board:

Length: unlimited.

Width: 60cm ---- 120cm (Adjustable)

Thickness: 1cm----15cm (Adjustable)



Mgo Board

Length: unlimited.

Width: Maximum 1.3 m (Adjustable)

Thickness: 2mm-60mm (Adjustable)

Standard Specification of the board is 1.22mX2.44m



2. Machine Model:

According to different production capacity from 800 square meters to 3000 square meters per eight hours wall board-making machine has different models for large-scale, middle-scale and small-scale.

All machine can produce board with same best-quality and specification board, only has different production capacity.

For whole production line, we have common one, semi-automatic one and full-automatic one, you can choose any kind of production line according to your own condition.



3. Application of Wall Board:

The wall board produced by our machine will replace solid brick as indoor partition, wall of steel structure and frame structure as well as wall of removable houses. Its products can be used for outside wall heat-preserving in northeast area of China.



4. Board performance:

1 Air-dry density ≤ (Standard index)50kg/m2 (Test Value) 30.0kg/ m2
2 Drying shrinkage rate of the board ≤0.08% 0.015%
3 Anti-breaking load ≥1400N 5640N
4 Anti-impact No breakage phenomenon such as cracking after three impacts No breakage phenomenon such as cracking after three impacts
5 Thermal resistance of main section (T=90mm) ≥1.35(m2.k)/w ≥1.36(m2.k)/w
6 Thermal bridges area ratio ≤8% 2.22%
7 Sound reduction Index   36dB
8 Radioactivity   None

Technical index:

1. Oxygenic index%: 90

2. Level combustion: SO

3. Vertical combustion: SO

4. Water content rate: 10.9%

5. Capacity: 1.15g/cm3

6. Static bending intensity: 169.46Mpa

7. Density: T/ m3 1.13

8. Water resistance: Without chalking for 24 hours and there is no change on surface

9. No “Three-wastes” (waste water, waste gas and waste residue), no pollution and environmental protection







(I) Cost accounting

Raw material cost: 15 Yuan/ Piece; Wage: 0.5Yuan/ Piece; Water-electricity fee: 0.2 Yuan/ Piece; Depreciation of the workshop: 0.2Yuan/ Piece; Total: 15.90 Yuan/ Piece

(II) Profit analysis: production: (Take the middle-scale equipment as example),400 pieces per day, at the common price of 40 Yuan/ Piece to sell, and then the profit per piece is that: 40 Yuan/ Piece-15.9 Yuan/ Piece=24.1 Yuan/ Piece, the profit per day is that: 400 pieces×24.1 Yuan/ Piece=9640Yuan
